Generating Separate Labels for Each Parcel

This document provides technical guidance on generating separate shipping labels for each parcel using the separate_parcel_labels parameter. By enabling this feature, each requested parcel receives its own individual label, simplifying logistics and improving shipment tracking.

Last updated About 1 year ago

Enabling Separate Parcel Labels

To generate individual labels for each parcel in a shipment, include the separate_parcel_labels parameter within the shipment object of your create-label request.

Request Example

{
	"testing": false,
	"auth_company": "company",
	"shipment": {
	    "label_size": "6x4",
	    "label_format": "pdf",
	    "generate_commercial_invoice": false,
	    "generate_packing_slip": false,

        "separate_parcel_labels" : true,

	    "courier" : {
	    	"friendly_service_name": "DHL 24H Service",
	        "global_product_code" : "U",
	        "local_product_code" : "U"
	    },

	    "collection_date": "2019-11-18T16:30:49.054Z",
	    "reference": "my reference",
	    "delivery_instructions":  "Leave on the porch",

	    "ship_from": {
	        "name": "MN",
	        "phone": "01377337164",
	        "email": "foo@foo.com",
	        "company_name": "Fake Company",
	        "address_1": "unit 76",
	        "address_2": "warfield road",
	        "address_3": "",
	        "city": "Driffield",
	        "postcode": "YO25 9DJ",
	        "county": "",
	        "country_iso": "GB",
	        "company_id": "911-70-1234",
	        "tax_id": "911-70-1234",
            "eori_id": "911-70-1234-000"
	    },

	    "ship_to": {
	        "name": "Laura Maura",
	        "phone": "466546346546",
	        "email": "support@buyer.com",
	        "company_name": "",
	        "address_1": "Ekeredsvaegen 132",
	        "address_2": "",
	        "address_3": "",
	        "city": "Lerum",
	        "county": "",
	        "postcode": "443 50",
	        "country_iso": "SE"
	    },
	    "parcels": [
        {
            "dim_width": 20,
            "dim_height": 40,
            "dim_length": 40,
            "dim_unit": "cm",

            "items": [
                {
                    "description": "Test Item One",
                    "origin_country": "GB",
                    "quantity": 2,
                    "value": 20,
                    "value_currency": "GBP",
                    "weight": 0.6,
                    "weight_unit": "kg",
                    "sku": "EXPICKLIST",
                    "hs_code": "12345"
                }, {
                    "description": "Test Item Two",
                    "origin_country": "GB",
                    "quantity": 1,
                    "value": 5,
                    "value_currency": "GBP",
                    "weight": 0.4,
                    "weight_unit": "kg",
                    "sku": "TEST0002",
                    "hs_code": "12345"
                }]
        },
        {
            "dim_width": 20,
            "dim_height": 40,
            "dim_length": 40,
            "dim_unit": "cm",

            "items": [
                {
                    "description": "Test Item One",
                    "origin_country": "GB",
                    "quantity": 2,
                    "value": 20,
                    "value_currency": "GBP",
                    "weight": 0.6,
                    "weight_unit": "kg",
                    "sku": "EXPICKLIST",
                    "hs_code": "12345"
                }, {
                    "description": "Test Item Two",
                    "origin_country": "GB",
                    "quantity": 1,
                    "value": 5,
                    "value_currency": "GBP",
                    "weight": 0.4,
                    "weight_unit": "kg",
                    "sku": "TEST0002",
                    "hs_code": "12345"
                }]
        }
        ]
	},
	"format_address_default" : true,
	"request_id": 123456789
}

Response Example

When separate_parcel_labels is set to true, the response includes an array of parcel labels, where each parcel has a unique label.

{
    "type": "PDF",
    "request_id": "1637676622",
    "tracking_codes": [
        "ZT4523619HHHH", "ZT4523619HHHI"
    ],
    "tracking_urls": [
        "https://www.royalmail.com/track-your-item#/tracking-results/ZT4",
        "https://www.royalmail.com/track-your-item#/tracking-results/ZT6"
    ],
    "uri": "https://example.com/parcels.pdf",
    "key": "rm_rZJaEb09JLfRjGLOk.pdf",
    "dc_request_id": 48820754,
    "tracking_request_id": 48820754,
    "tracking_request_hash": 536556463,
    "label_size": "6x4",
    "courier": "RoyalMail",

     "parcel_labels" : [
        {
            "uri": "https://example.com/parcel1.pdf",
            "key": "parcelmerge_38MFmJO3EHS8IXuyzBkZ.pdf",
            "parcel_number": 1,
            "parcel_identifier": "48820754-1",
            "parcel": {
                "dim_length": 10,
                "dim_width": 10,
                "dim_height": 10,
                "dim_unit": "CM",
                "items": [
                    {
                        "sku": "SKU01",
                        "description": "garden tool kit",
                        "value": 8,
                        "value_currency": "GBP",
                        "quantity": 1,
                        "origin_country": null,
                        "weight": 0.65,
                        "weight_unit": null,
                        "_original_value": 8
                    }
                ],
                "_summed_item_weights": 0.65,
                "_summed_total_weight": 0.65
            }
        },
        {
            "uri": "https://example.com/parcel2.pdf",
            "key": "parcelmerge_bQeiFfBmmyYdkGhiuoVs.pdf",
            "parcel_number": 2,
            "parcel_identifier": "48820754-2",
            "parcel": {
                "dim_length": 10,
                "dim_width": 10,
                "dim_height": 10,
                "dim_unit": "CM",
                "items": [
                    {
                        "sku": "SKU01",
                        "description": "2 tool kit",
                        "value": 8,
                        "value_currency": "GBP",
                        "quantity": 1,
                        "origin_country": null,
                        "weight": 0.65,
                        "weight_unit": null,
                        "_original_value": 8
                    }
                ],
                "_summed_item_weights": 0.65,
                "_summed_total_weight": 0.65
            }
        }
    ]
}

Each parcel label can be downloaded via the provided uri link.

Summary

  • Include separate_parcel_labels: true in the shipment object of your request.

  • The response will contain a parcel_labels array with individual label URLs.

  • Each parcel in the shipment will have its own separate label, improving clarity and efficiency in logistics.

For further details, refer to the API documentation or contact technical support.
